Intel Core i5-13600K processor 24 MB Smart Cache Box
- Beschrijving
Beschrijving
Beschrijving
Specificaties
Processor
Processorfabrikant
Merknaam van de fabrikant die de processor heeft geproduceerd.
Intel
Processorgeneratie
Intel® 13de generatie Core™ i5
Processormodel
The model number for the processor in a computer.
i5-13600K
Processorfamilie
A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors.
Intel® Core™ i5
Aantal processorkernen
The number of central processing units (‘cores’) in a processor. Some processors have 1 core
14
Processor socket
Mechanical component(s) that provides mechanical and electrical connections between a microprocessor and a printed circuit board (PCB). This allows the processor to be replaced without soldering.
LGA 1700
Processor aantal threads
20
Processor operating modes
Operating modes for the processors that place restrictions on the type and scope of operations for certain processes run by the CPU. This design allows the operating system to run with more privileges than application software.
64-bit
Prestatiekernen
6
Efficiënte kernen
8
Maximale turbofrequentie van processor
De turboboost is een automatische, gemanagde versnelling van de processor wanneer een van de processorkernen overbelast dreigt te raken.
5,1 GHz
Prestatie-kernboostfrequentie
5,1 GHz
Prestatie-kernbasisfrequentie
3,5 GHz
Efficiënte kernboostfrequentie
3,9 GHz
Efficiënte kernbasisfrequentie
2,6 GHz
Processor cache
24 MB
Processor cache type
Smart Cache
Box
Plastic or metal shell/container for components.
Inclusief koeler
The device comes with an integrated cooler.
Processor basisvermogen
125 W
Maximaal turbovermogen
181 W
Stepping
B0
Bus type
DMI4
Maximum aantal DMI lanes
8
Geheugenbandbreedte ondersteund door de processor ( max)
89,6 GB/s
Codenaam processor
Raptor Lake
ARK ID processor
230493
Geheugen
Maximaal intern geheugen ondersteund door processor
192 GB
Geheugentypen ondersteund door processor
DDR4-SDRAM, DDR5-SDRAM
Geheugen kanaal
Dubbelkanaals
ECC
ECC (Error Correction Code)-geheugen is geheugen dat in staat is om sommige geheugenproblemen op te lossen zonder gebruikersbemoeienis.
Non-ECC
Geheugen bandbreedte (max)
89,6 GB/s
Grafisch
Ingebouwde grafische adapter
Graphics hardware which is built into the motherboard or CPU
Aparte grafische adapter
On-board graphics adapter model
“Graphic adapter” is the hardware that produces images on a display. “On-board” means that the graphics adapter is intergrated inside the motherboard.
Intel UHD Graphics 770
On-board ondersteunde grafische adapter uitgangen
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
Basisfrequentie ingebouwde grafische adapter
300 MHz
Graphics on-board -adapter dynamische frequentie (max)
1500 MHz
Aantal displays ondersteund (door on-board grafische adapter)
The feature may not be available on all computing systems. Functionality, performance, and other benefits of this feature may vary depending on system configuration.
4
On-board grafische adapter DirectX-versie
12.0
On-board grafische adapter OpenGL versie
4.5
Graphics aan boord maximale resolutie adapter (DisplayPort )
7680 x 4320 Pixels
Maximale resolutie (eDP – Integrated Flat Panel)
5120 x 3200 Pixels
Maximale resolutie ingebouwde grafische adapter (HDMI)
4096 x 2160 Pixels
Grafische adapter refresh rate on-board bij maximale resolutie (DisplayPort )
60 Hz
Refresh rate op maximale resolutie (eDP – Integrated Flat Panel)
120 Hz
Verversingsfrequentie ingebouwde grafische adapter bij maximale resolutie (HDMI)
60 Hz
On-board grafische adapter ID
0xA780
Discreet grafische adapter model
A graphics adapter (often known as a video card) generates images for a display. A discrete graphics adapter plugs into the motherboard
Niet beschikbaar
Aantal verwerkingseenheden
32
Multi-Formaat Codec-motoren
2
Kenmerken
Execute Disable Bit
Idle States
Thermal Monitoring Technologies
Marktsegment
Desktop
Gebruiksvoorwaarden
PC/Client/Tablet
Kenmerken
Maximaal aantal PCI Express-lijnen
20
PCI Express slots versie
4.0, 5.0
PCI Express configuraties
1×16+1×4, 2×8+1×4
Ondersteunde instructie sets
SSE4.1, SSE4.2, AVX 2.0
Schaalbaarheid
1S
CPU configuratie (max)
1
Ingebouwde opties beschikbaar
Directe media-interface (DMI) revisie
4.0
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
740.17B1
Processor speciale functies
Intel® Hyper Threading Technology (Intel® HT Technology)
Verbeterde prestaties voor threaded software Intel® Hyper-Threading Technologie (Intel® HT Technologie) maakt efficiënt gebruik van de processorkracht door verschillende threads op iedere core te laten draaien en de verwerkingssnelheid van de processor te verhogen. Beschikbaar voor Intel® Core™ en Intel® Xeon® processors. Intel HT Technologie helpt om veeleisende applicaties tegelijk te laten draaien, om systemen te beschermen en te beheren en om ruimte voor bedrijfsgroei te maken.
Intel® Turbo Boost Technology
Hogere prestaties wanneer u het nodig hebt Intel® Turbo Boost Technologie 2.0 versnelt de prestaties van de processor en de grafische prestaties door de werkfrequentie te verhogen als er onder de specificatiegrenzen gewerkt wordt. De maximale frequentie varieert afhankelijk van de werklast, hardware, software en de algehele systeemconfiguratie.
2.0
Intel® Quick Sync Video Technology
Maak, bewerk en deel video’s in een oogwenk Intel® Quick Sync Video gebruikt de daarvoor bestemde mediaverwerkingsmogelijkheden van Intel® Graphics Technologie om videocodering nog sneller en gemakkelijker te maken. Denk hierbij aan het maken van dvd’s of Blu-ray discs, het maken en bewerken van 3D-video’s, het converteren van 2D-videobestanden naar 3D en het converteren van video’s voor draagbare mediaspelers en sociale netwerksites.
Intel® Clear Video HD Technology (Intel® CVT HD)
Bekijk de wereld op een levendigere manier Intel® Clear Video HD Technologie zorgt voor heldere, scherpe beelden en natuurlijke, nauwkeurige en levendige kleuren. Bekijk beelden zoals ze bedoeld zijn met Intel® Graphics Technology op apparaten met Intel® Core™ processors.
Intel® AES New Instructions (Intel® AES-NI)
Extra veiligheid met snellere data-encryptie De Intel® Advanced Encryption Standard New Instructions (Intel® AES-NI) maakt snelle en veilige data-encryptie en -decryptie mogelijk voor een betere prestatie en minder risico door tijd- en cache-gebaseerde aanvallen dan bij table-based software-implementaties. Intel AES-NI ondersteunt het gebruik van standaard sleutellengtes, standaardwerkwijzen en zelfs sommige niet-standaard of toekomstige varianten.
Enhanced Intel SpeedStep Technology
Intel® Trusted Execution Technology
Intel® Speed Shift-technologie
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Intel® Control-flow Enforcement Technology (CET)
Intel® Thread Director
Intel® VT-x with Extended Page Tables (EPT)
Intel® Secure Key
Maak cryptografische beveiligingsprotocollen Intel® Secure Key is een hardware-based toevalsgenerator die ter beveiliging hoogwaardige sleutels kan genereren voor cryptografische protocollen (encryptie en decryptie). Deze sleutels bieden kwaliteitsentropie die veel gevraagd wordt in de wereld van de cryptografie als extra beveiliging.
Intel® Active Management Technology (Intel® AMT)
Verhoog de efficiëntie en effectiviteit automatisch en op afstand Door het gebruik van geïntegreerde platformmogelijkheden en managementapplicaties van derden maakt Intel® Active Management Technologie (Intel® AMT) het mogelijk voor IT of managed serviceproviders om netwerkapparaten op afstand te beheren. Zelfs als de apparaten uitgeschakeld zijn, kunnen ze gediagnosticeerd en gerepareerd worden, software- en virusupdates ontvangen of data opslaan. Hierdoor worden de kosten voor IT-ondersteuning lager.
Intel® Stable Image Platform Program (SIPP)
Intel® OS Guard
Bescherm uw werkomgeving Intel® OS Guard is een hardware-gebaseerde beveiligingsfunctie die de kernel van het besturingssysteem beschermt en verdedigt tegen kwaadaardige data of code-aanvallen in zones van het geheugen die gemarkeerd zijn als gebruikersmoduspagina’s. Daarnaast wordt voorkomen dat een applicatie de OS kernel kan overnemen of in gevaar kan brengen.
Intel® 64
Intel® Virtualization Technology (VT-x)
Simplify Virtualization and Reduce Overheads Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
Intel® Virtualization Technology for Directed I/O (VT-d)
Simplify Virtualization and Reduce Overheads Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
Intel® Turbo Boost Max Technology 3.0
Intel® Boot Guard
Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.
Intel® Deep Learning Boost (Intel® DL Boost)
Intel® Volume Management Device (VMD)
Mode-based Execute Control (MBE)
Intel® vPro™ Platform Eligibility
Intel® Standard Manageability (ISM, Standaard beheerbaarheid)
Intel® One-Click Recovery (Herstel met 1 klik)
Intel® Stabiel IT-platformprogramma (SIPP)
Intel® Remote Platform Erase (RPE)
Intel® virtualisatietechnologie met omleidingsbescherming (VT-rp)
Intel vPro® Enterprise-platformvoorwaarden
Intel®-technologie voor dreigingsdetectie (TDT)
Intel® Hardware Shield-voorwaarden
Intel® totale geheugencodering – Meerdere sleutels
Intel vPro® Essentials-platformvoorwaarden
